CQF16-06ENSEW1 6068626
Product Overview
New original SICK CQF16-06ENSEW1 capacitive level sensor, PN 6068626, compact rectangular CQF series sensor. Sensing range 0.5~6mm, NPN NO output, 10-30VDC power supply. It is equipped with 2m 4-core PVC cable, IP67/IP68/IP69K high protection grade. Supports cable teach-in setting, suppresses foam and residue interference effectively. Working temperature -25℃ ~ +80℃. Suitable for water-based liquid detection in food, beverage and pharmaceutical automation equipment. We supply genuine SICK sensors with fast delivery and reliable after-sales service.
| 属性名 | 属性值 |
|---|---|
| Brand | SICK |
| Model | CQF16-06ENSEW1 |
| Part No. | 6068626 |
| Series | CQF |
| Sensor type | Capacitive level sensor |
| Sensing distance | 0.5 ~ 6 mm |
| Installation | Flush / Non-flush mount |
| Output type | NPN, NO |
| Wiring | DC 4-wire |
| Connection | 2m 4-core PVC cable |
| Supply voltage | 10–30 V DC |
| Max switching current | 100 mA |
| Switching frequency | 10 Hz |
| IP rating | IP67, IP68, IP69K |
| Housing material | PBT plastic |
| Operating temperature | -25 ℃ ~ +80 ℃ |
| Feature | Cable teach-in function, anti-foam interference, detect water-based liquid |
| Weight(net) | 0.07 kg |
| Weight(gross) | 0.13 kg |
| Certificate | RoHS, cULus, Ecolab |
