CM30-16BNP-EWDS03 6080314
Product Overview
New original SICK CM30-16BNP-EWDS03 capacitive proximity sensor, PN 6080314, CM series M30 threaded flush mount type. It features 16 mm rated sensing distance, complementary NPN output, 10–36 V DC power supply, max 200 mA switching current and 50 Hz switching frequency. Equipped with 0.3m cable and AMP 3-pin male connector, IP68/IP69K high protection grade, PBT plastic housing, adjustable sensitivity by potentiometer with wire configurable output. Wide working temperature from -30℃ to +85℃, stable performance for harsh industrial environments. Widely used for material level detection, object counting and position monitoring in automation, packaging and conveyor systems. We supply genuine SICK sensors with fast delivery and reliable after-sales support.
| 属性名 | 属性值 |
|---|---|
| Brand | SICK |
| Model | CM30-16BNP-EWDS03 |
| Part No. | 6080314 |
| Series | CM |
| Sensor type | Capacitive proximity sensor |
| Sensing distance | 16 mm |
| Installation | Flush mount |
| Output type | NPN, complementary |
| Wiring | DC 4-wire |
| Connection | 0.3m cable with AMP 3-pin male connector |
| Supply voltage | 10–36 V DC |
| Max switching current | 200 mA |
| Switching frequency | 50 Hz |
| IP rating | IP68, IP69K |
| Housing material | PBT plastic |
| Operating temperature | -30 ℃ ~ +85 ℃ |
| Feature | Sensitivity adjustable by potentiometer, wire configurable output |
| Weight(net) | 0.11 kg |
| Weight(gross) | 0.17 kg |
| Certificate | RoHS |
