MN1H-5/2-D-1-C
Product Overview
MN1H-5/2-D-1-C (Part No.159688) is Festo MN1H Tiger Classic series pilot operated solenoid valve, complying with ISO 5599-1 size 1 standard. It is a 5/2-way monostable single solenoid valve with spring return, internal pilot design, G1/4 port and 1200 l/min nominal flow rate. This valve body needs to be matched with separate solenoid coil and socket, widely used for controlling double-acting pneumatic cylinders in industrial pneumatic automation systems.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | MN1H-5/2-D-1-C |
| Part No. | 159688 |
| Product Type | Pneumatic Pilot Solenoid Valve |
| Series | MN1H (Tiger Classic) |
| Valve Function | 5/2-way, monostable (single solenoid, spring return) |
| Construction Width | 42 mm |
| Sub-base Standard | ISO 5599-1, Size 1 |
| Port Size | G1/4 |
| Nominal Flow | 1200 l/min |
| Operating Pressure | 2 ~ 10 bar |
| Pilot Air | Internal pilot |
| Structure | Piston gate valve |
| Sealing Type | Soft seal (NBR+HNBR) |
| Protection Class | IP65 |
| Switching Time ON | 23 ms |
| Switching Time OFF | 32 ms |
| Flow Direction | Reversible |
| Mounting | Install on sub-base, through-hole mounting |
| Operating Medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Ambient Temperature | -10 ~ +60 ℃ |
| Housing Material | Die-cast aluminium |
| Seal Material | NBR, HNBR |
| CRC Corrosion Class | CRC2 |
| LABS Compliance | VDMA24364-B1/B2-L |
| Net Weight | 0.45 kg |
| Gross Weight | 0.52 kg |
| Certification | cULus Recognized |
| RoHS | Compliant |
| Condition | New Original |
| Application | Pneumatic cylinder control, industrial automation, machine tool, packaging machinery |
