SPZ-58Z-008-P

Attribute Name	Value
Brand	Koyo
Model	SPZ-58Z-008-P
Series	SPZ Series Incremental Rotary Encoder
Type	Incremental Rotary Encoder
Resolution	8 PPR
Outer Diameter	Φ58mm
Shaft Diameter	Φ10mm Solid Shaft
Output Type	Push-pull Output
Power Supply	DC12~24V
Channel	A, B, Z Phase
Protection Class	IP50
Operating Temp	-20℃ ~ +70℃
Cable Outlet	Side cable outlet
Net Weight	0.32kg
Gross Weight	0.42kg
Origin	China
Warranty	1 year
Condition	New Original
Application	Speed measurement, positio

INQUIRY

Product Details

Product Tags

Product Overview

Koyo SPZ-58Z-008-P incremental rotary encoder belongs to SPZ series. It has 8 pulses per revolution, Φ58mm housing with Φ10mm solid shaft. Output is push-pull type with A, B, Z three phase signals. Working power DC12~24V, protection grade IP50. Side cable outlet design. Operating temperature -20℃ ~ +70℃. It converts rotation speed and angular position into digital pulse signal for PLC control. Suitable for low speed heavy torque equipment speed monitoring, conveyor and lifting machinery.

Attribute Name	Value
Brand	Koyo
Model	SPZ-58Z-008-P
Series	SPZ Series Incremental Rotary Encoder
Type	Incremental Rotary Encoder
Resolution	8 PPR
Outer Diameter	Φ58mm
Shaft Diameter	Φ10mm Solid Shaft
Output Type	Push-pull Output
Power Supply	DC12~24V
Channel	A, B, Z Phase
Protection Class	IP50
Operating Temp	-20℃ ~ +70℃
Cable Outlet	Side cable outlet
Net Weight	0.32kg
Gross Weight	0.42kg
Origin	China
Warranty	1 year
Condition	New Original
Application	Speed measurement, position feedback, conveyor, hoisting equipment, automation machinery, motor speed acquisition, low-speed heavy torque equipment speed monitoring
