WTB12F-24161120A00ZDZZZZZZZZZ1
Product Details
The SICK WTB12F-24161120A00ZDZZZZZZZZZ1 is a brand-new original diffuse reflection photoelectric sensor from the W12 series. It adopts visible red LED light source and runs on 10–30 V DC power supply, with PNP output and switchable Light-ON / Dark-ON function for convenient connection to various PLC control systems. It has IP67 protection grade for reliable dust and moisture resistance in tough industrial workshop environments.
Built with sturdy zinc die-cast metal rectangular housing, this sensor is equipped with M12 4-pin connector for quick installation and wiring. It detects objects by capturing light reflected directly from the target surface, no reflector required.
This sensor is widely used for object detection on conveyor belts, packaging machinery and material handling automated production lines. Each unit undergoes complete quality inspection before shipment and comes with CE certification. We supply genuine SICK sensors with MOQ of 1 piece and provide stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTB12F-24161120A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Diffuse Reflection Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Diffuse reflection object detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension(W×H×D) | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -25℃ ~ +55℃ |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, conveyor, packaging machinery, material handling automation |
| Certificate | CE |
| MOQ | 1 Piece |
