WTF12F-34162120A00ZDZZZZZZZZZ1
Product Details
The SICK WTF12F-34162120A00ZDZZZZZZZZZ1 is a brand-new original retro-reflective photoelectric sensor belonging to the W12 series. It is equipped with visible red LED light source and runs on 10–30 V DC power supply, featuring PNP output and switchable Light-ON / Dark-ON function for convenient connection with industrial automation systems. It has an IP67 protection rating to prevent damage from dust and moisture, ensuring stable performance in factory environments.
Constructed with sturdy zinc die-cast rectangular metal housing, this sensor uses M12 4-pin connector for fast wiring and installation. Its sensing range covers 0.1 meter to 7 meters. It detects objects once the light beam between the sensor and reflector is blocked.
This photoelectric sensor is widely applied for object detection in packaging machinery, conveyor belts and material handling automated production lines. Each unit undergoes strict pre-shipment quality inspection and comes with CE certification. We supply genuine SICK sensors with MOQ of 1 piece and provide stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTF12F-34162120A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Retro-reflective Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Retro-reflective detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -25℃ ~ +55℃ |
| Sensing Range | 0.1~7m |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, packaging machinery, conveyor automation, material handling |
| Certificate | CE |
| MOQ | 1 Piece |
