WTM12F-24161120A00ZDZZZZZZZZZ1
Product Details
The SICK WTM12F-24161120A00ZDZZZZZZZZZ1 is a brand-new original retro-reflective photoelectric sensor from the W12 series. It is equipped with visible red LED light source and operates within 10–30 V DC power supply, featuring PNP output and switchable Light-ON / Dark-ON function for easy connection to various PLC control systems. It has IP67 protection grade for excellent dust and moisture resistance in harsh industrial environments.
Made of sturdy zinc die-cast rectangular metal housing, this sensor uses M12 4-pin connector for quick installation and wiring. It needs a matching reflector. Once objects block the red light beam between the sensor and reflector, the sensor will send out detection signals.
This sensor is widely used for object detection on conveyor belts, packaging machinery and material handling automated production lines. Every unit undergoes strict pre-shipment quality inspection and has CE certification. We supply genuine SICK sensors with MOQ of 1 piece and offer stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTM12F-24161120A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Retro-reflective Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Retro-reflective detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension(W×H×D) | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -25℃ ~ +55℃ |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, conveyor, packaging machinery, material handling automation |
| Certificate | CE |
| MOQ | 1 Piece |
