WTS12F-24161120A00ZDZZZZZZZZZ1
Product Details
The SICK WTS12F-24161120A00ZDZZZZZZZZZ1 is a brand-new original diffuse reflection photoelectric sensor of the W12 series. It is equipped with visible red LED light source and works under 10–30 V DC power supply, featuring PNP output and switchable Light-ON / Dark-ON function for connection with various industrial automation control systems. It has IP67 protection rating to resist dust and moisture, suitable for common factory environments.
Constructed with solid zinc die-cast rectangular metal housing, this sensor adopts M12 4-pin connector for fast wiring and installation, and it comes with adjustable sensing range to meet diverse object detection requirements.
This photoelectric sensor is widely applied in packaging machinery, conveyor belts and material handling automated production lines. Each unit undergoes strict quality inspection before shipment and holds CE certification. We supply genuine SICK sensors with MOQ of 1 piece and provide stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTS12F-24161120A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Diffuse Reflection Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Diffuse reflection detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -25℃ ~ +55℃ |
| Sensing Range | Adjustable |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, packaging machinery, conveyor automation, material handling |
| Certificate | CE |
| MOQ | 1 Piece |
