WTS12F-34161120A00ZDZZZZZZZZZ1
Product Details
The SICK WTS12F-34161120A00ZDZZZZZZZZZ1 is a brand-new original retro-reflective photoelectric sensor from the W12 series. It uses visible red LED light source and operates under 10–30 V DC power supply, equipped with PNP output and switchable Light-ON / Dark-ON function for easy integration with industrial control systems. It has an IP67 protection rating for dust and moisture resistance, with a sensing range from 0.1m up to 7 meters.
Made of sturdy zinc die-cast rectangular metal housing, this sensor adopts M12 4-pin connector for fast mounting and wiring. It detects objects when the optical beam between the sensor and reflector is blocked.
This photoelectric sensor is widely applied in packaging machinery, conveyor belts and material handling automated production lines. Each unit undergoes strict quality inspection before shipment and holds CE certification. We supply genuine SICK sensors with MOQ of 1 piece and provide stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTS12F-34161120A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Retro-reflective Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Retro-reflective detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -25℃ ~ +55℃ |
| Sensing Range | 0.1m ~ 7m |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, packaging machinery, conveyor automation, material handling |
| Certificate | CE |
| MOQ | 1 Piece |
