VMEF-ST-M32-M-G18
Product Overview
VMEF-ST-M32-M-G18 (Part No.8086074) is Festo VMEF series pneumatically piloted pulse jet diaphragm valve. Main port M32 male thread, pilot control port G1/8. When pilot air signal triggers, valve opens instantly and releases high-pressure air pulse to blow dust off filter bags/cartridges. Fast response, reliable diaphragm sealing, suitable for continuous operation in dust collection environment.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | VMEF-ST-M32-M-G18 |
| Part No. | 8086074 |
| Product Type | Pneumatic Pulse Jet Valve / Diaphragm Pulse Valve |
| Series | VMEF |
| Main Connection | M32 male thread |
| Pilot Control Port | G1/8 |
| Actuation Type | Pneumatically piloted |
| Operating Pressure | 0.4 ~ 6 bar |
| Nominal Diameter | 25 mm |
| Medium | Compressed air, dry filtered air |
| Ambient Temperature | -20 ~ +80 ℃ |
| Housing Material | Cast aluminium alloy |
| Diaphragm Material | NBR |
| Seal Material | NBR |
| Mounting Position | Optional |
| CRC Corrosion Class | CRC2 |
| LABS Compliance | VDMA24364-B1/B2-L |
| Net Weight | 0.520 kg |
| Gross Weight | 0.60 kg |
| RoHS | Compliant |
| Condition | New Original |
| Application | Dust collector bag filter, pulse jet cleaning, industrial dust removal system |
