U-1/2-B
Product Overview
Festo U-1/2-B (Part No.6844) is U-series high-flow pneumatic exhaust silencer. It is installed on exhaust ports of large flow solenoid valves and pneumatic valve islands to reduce exhaust noise and prevent dust from entering pneumatic components. Aluminum body with PE inner damping insert, large flow capacity for heavy-duty pneumatic systems.
| 属性名称 | 属性值 |
|---|---|
| Brand | Festo |
| Model | U-1/2-B |
| Part Number | 6844 |
| Product Type | Pneumatic Silencer / Exhaust Muffler |
| Series | U Series |
| Pneumatic Port | G1/2 Male Thread |
| Flow Rate to Atmosphere | 7500 l/min |
| Operating Pressure | 0 ~ 10 bar |
| Sound Pressure Level | 81 dB(A) |
| Medium | Compressed air ISO 8573-1:2010 [7:-:-], lubricated air allowed |
| Ambient Temperature | -10 ~ +70 ℃ |
| Medium Temperature | -10 ~ +70 ℃ |
| Mounting Position | Any mounting position |
| Housing Material | Aluminium |
| Silencer Insert Material | PE Polyethylene |
| Screw Plug Material | Aluminium |
| Weight | 75 g |
| CRC Class | CRC 1 |
| LABS(PWIS) | VDMA24364-B1/B2-L |
| RoHS | Compliant |
| Original/New | New Original |
