6033269 STE-1208-G

属性名称	属性值
Brand	SICK
Model	STE-1208-G
Order No.	6033269
Product Type	Sensor Cable / Connector Cable
Connector Type	M12 Female, Straight, A-coded
Pin	8 Pin
Cable Length	8 m
Core	8 Core
Conductor Cross Section	0.25 mm²
Cable Jacket Material	PUR
Color	Gray
Locking Nut	Zinc die-cast, nickel-plated
Shielding	Unshielded
Rated Voltage	≤60 V DC
Rated Current	4 A
IP Rating	IP65 / IP66K / IP67
Tightening Torque	0.6 Nm
Feature	Drag chain suitable, Oil resistant
Operating Temperature	Fixed

INQUIRY

Product Details

Product Tags

Product Overview

STE-1208-G (Part No.6033269) is SICK M12 sensor actuator cable. Equipped with 8-pin A-coded straight female connector, cable length of 8 meters. Adopting PUR jacket, unshielded structure, oil resistant and suitable for drag chain wiring. With IP67 protection, it provides reliable signal transmission for sensors and actuators in automated machinery and production systems.

属性名称	属性值
Brand	SICK
Model	STE-1208-G
Order No.	6033269
Product Type	Sensor Cable / Connector Cable
Connector Type	M12 Female, Straight, A-coded
Pin	8 Pin
Cable Length	8 m
Core	8 Core
Conductor Cross Section	0.25 mm²
Cable Jacket Material	PUR
Color	Gray
Locking Nut	Zinc die-cast, nickel-plated
Shielding	Unshielded
Rated Voltage	≤60 V DC
Rated Current	4 A
IP Rating	IP65 / IP66K / IP67
Tightening Torque	0.6 Nm
Feature	Drag chain suitable, Oil resistant
Operating Temperature	Fixed: -40℃~+80℃, Drag chain: -25℃~+80℃, Connector: -25℃~+85℃
Certification	UL
Condition	New Original
MOQ	1 Piece
Gross Weight	0.21 KG
Net Weight	0.19 KG
Place of Origin	Germany
