YG2A14-050VB3XLEAX

属性名称	属性值
Brand	SICK
Model	YG2A14-050VB3XLEAX
Order No.	2094864
Product Type	Sensor Actuator Cable
Connector Type	M12 Female, Straight, A-coded
Pin	4 Pin
Core	4 Core
Cable Length	5 m
Conductor Cross Section	0.25 mm²
Cable Jacket Material	PUR, Halogen-free
Color	Gray
Locking Nut	Nickel-plated zinc die-cast
Shielding	Unshielded
Rated Voltage	≤60 V DC
Rated Current	4 A
IP Rating	IP65 / IP66K / IP67
Tightening Torque	0.6 Nm
Feature	Drag chain suitable, Oil resistant
Operating Tempe

INQUIRY

Product Details

Product Tags

Product Overview

YG2A14-050VB3XLEAX (Part No.2094864) is SICK M12 sensor actuator cable. It adopts 4-pin A-coded straight female connector, cable length 5 meters. This cable uses halogen-free PUR jacket, unshielded design, oil resistant and suitable for drag chain wiring. With IP67 protection, it provides stable signal connection for sensors and actuators in automated equipment and production lines.

属性名称	属性值
Brand	SICK
Model	YG2A14-050VB3XLEAX
Order No.	2094864
Product Type	Sensor Actuator Cable
Connector Type	M12 Female, Straight, A-coded
Pin	4 Pin
Core	4 Core
Cable Length	5 m
Conductor Cross Section	0.25 mm²
Cable Jacket Material	PUR, Halogen-free
Color	Gray
Locking Nut	Nickel-plated zinc die-cast
Shielding	Unshielded
Rated Voltage	≤60 V DC
Rated Current	4 A
IP Rating	IP65 / IP66K / IP67
Tightening Torque	0.6 Nm
Feature	Drag chain suitable, Oil resistant
Operating Temperature	Fixed: -40℃~+80℃, Drag chain: -25℃~+80℃, Connector: -25℃~+85℃
Certification	UL
Condition	New Original
MOQ	1 Piece
Gross Weight	0.14 KG
Net Weight	0.12 KG
Place of Origin	Germany
