CQ35-25NNP-KW1 6021463
Product Overview
New original SICK CQ35-25NNP-KW1 capacitive proximity sensor, PN 6020477, CQ series rectangular non-flush mount type. It has 25 mm sensing distance, complementary NPN NO+NC output, 10–36 V DC supply, max 200 mA switching current and 50 Hz switching frequency. Fitted with 2m 4-core PVC cable, IP67 protection grade, PC plastic housing and potentiometer for sensitivity adjustment. Stable performance within -25℃ ~ +75℃. Commonly used for liquid and solid level detection, object sensing in conveyor, packaging and other industrial automation equipment. We provide authentic industrial sensors, fast delivery and professional after-sales service.
| 属性名 | 属性值 |
|---|---|
| Brand | SICK |
| Model | CQ35-25NNP-KW1 |
| Part No. | 6020477 |
| Series | CQ |
| Sensor type | Capacitive proximity sensor |
| Sensing distance | 25 mm |
| Installation | Non-flush mount |
| Output type | NPN, NO+NC complementary |
| Wiring | DC 4-wire |
| Connection | 2m 4-core PVC cable |
| Supply voltage | 10–36 V DC |
| Max switching current | 200 mA |
| Switching frequency | 50 Hz |
| IP rating | IP67 |
| Housing material | PC plastic |
| Operating temperature | -25 ℃ ~ +75 ℃ |
| Feature | Sensitivity adjustable by potentiometer |
| Weight(net) | 0.14 kg |
| Weight(gross) | 0.20 kg |
| Certificate | RoHS |
