CQ28-10NNP-KW1 6030133

属性名	属性值
Brand	SICK
Model	CQ28-10NNP-KW1
Part No.	6030133
Series	CQ
Sensor type	Capacitive proximity sensor
Sensing distance	1 ~ 10 mm
Installation	Non-flush mount
Output type	NPN, NO+NC complementary
Wiring	DC 4-wire
Connection	2m 4-core PVC cable
Supply voltage	10–30 V DC
Max switching current	200 mA
Switching frequency	10 Hz
IP rating	IP68
Housing material	PBT plastic
Operating temperature	-20 ℃ ~ +85 ℃
Feature	Teach-in function, high EMC, detect liquid/powder/granule
Weight(

INQUIRY

Product Details

Product Tags

Product Overview

New original SICK CQ28-10NNP-KW1 capacitive proximity sensor, PN 6030133, rectangular CQ series non-flush mount sensor. Sensing range 1~10mm, NPN NO+NC complementary output, 10-30VDC power supply. It comes with 2m 4-core PVC cable and IP68 protection grade. Equipped with teach-in function and excellent EMC performance, it can stably detect liquid, powder and granular materials. Working temperature -20℃ ~ +85℃. It is widely used for level monitoring and object detection on packaging, conveyor and other industrial automation lines. We supply genuine SICK sensors with fast delivery and professional after-sales support.

属性名	属性值
Brand	SICK
Model	CQ28-10NNP-KW1
Part No.	6030133
Series	CQ
Sensor type	Capacitive proximity sensor
Sensing distance	1 ~ 10 mm
Installation	Non-flush mount
Output type	NPN, NO+NC complementary
Wiring	DC 4-wire
Connection	2m 4-core PVC cable
Supply voltage	10–30 V DC
Max switching current	200 mA
Switching frequency	10 Hz
IP rating	IP68
Housing material	PBT plastic
Operating temperature	-20 ℃ ~ +85 ℃
Feature	Teach-in function, high EMC, detect liquid/powder/granule
Weight(net)	0.12 kg
Weight(gross)	0.18 kg
Certificate	RoHS
