SMT-8-SL-PS-LED-24-B
Product Overview
FESTO SMT-8-SL-PS-LED-24-B magneto-resistive proximity sensor belongs to SMT-8-SL series, designed for T-slot pneumatic cylinders. PNP 3-wire normally open output, rated DC24V, M8×1 3-pin A-coded plug. Equipped with yellow LED for switching status indication. Built-in reverse polarity and short-circuit protection, repeat accuracy 0.2mm, max switching frequency 140Hz. LABS compliant, IP65/IP68 high protection, compact lightweight design only 4.2g. It can be inserted lengthwise into cylinder T-slot, easy installation and adjustment, widely used for piston position detection of pneumatic cylinders in automation systems.
| 属性名称 | 属性值 |
|---|---|
| Brand | FESTO |
| Model | SMT-8-SL-PS-LED-24-B |
| Order No. | 562019 |
| Product Series | SMT-8-SL |
| Product Type | Magneto-resistive Proximity Sensor / Cylinder Position Sensor |
| Mounting Type | T-slot, lengthwise insertion |
| Measuring Principle | Magneto-resistive |
| Output Type | PNP, 3-wire, Normally Open (N/O) |
| Rated Voltage | DC 24V |
| Operating Voltage Range | DC 10 ~ 30V |
| Max Output Current | 100 mA |
| Electrical Connection | M8x1, 3-pin A-coded plug |
| Status Indicator | Yellow LED switching display |
| Max Switching Frequency | 140 Hz |
| Repeat Accuracy | 0.2 mm |
| Ambient Temperature | -20 ~ +70 ℃ |
| Feature | Reverse polarity protection, short-circuit protection, LABS compliant (VDMA24364-B2-L) |
| Housing Material | High-alloy stainless steel / PA |
| Weight | 4.2 g |
| Protection Class | IP65, IP68 |
| Standard | EN 60947-5-2 |
| Certificate | CE, cULus, RCM, RoHS |
| Origin | Germany |
| Condition | New Original |
