DFS60B-TJEK01024

属性名称	属性值
Brand	SICK
Model	DFS60B-TJEK01024
Product Type	Incremental Rotary Encoder
Connector Type	M12 Straight, 8 Pin
Pin	8 Pin
Pulse Per Revolution	1024 ppr
Shaft Type	Solid shaft
Shaft Diameter	10 mm
Output Signal	Line driver (RS422)
Supply Voltage	4.75…30 V DC
Max Speed	6000 rpm
IP Rating	IP65
Housing Material	Aluminum alloy
Operating Temperature	-20℃~+70℃
Feature	1024ppr, solid shaft, M12 8pin connector, stable RS422 signal, shock resistant, compact aluminum housing
Certifica

INQUIRY

Product Details

Product Tags

Product Overview

DFS60B-TJEK01024 is SICK incremental rotary encoder. It has 1024 ppr resolution, equipped with 10mm solid shaft and 8-pin M12 straight connector. RS422 line driver output, supply voltage 4.75~30 V DC, max rotating speed up to 6000 rpm. Aluminum alloy housing with IP65 protection grade. Featuring shock resistance and stable pulse output, it provides accurate speed and position feedback for industrial motion control devices.

属性名称	属性值
Brand	SICK
Model	DFS60B-TJEK01024
Product Type	Incremental Rotary Encoder
Connector Type	M12 Straight, 8 Pin
Pin	8 Pin
Pulse Per Revolution	1024 ppr
Shaft Type	Solid shaft
Shaft Diameter	10 mm
Output Signal	Line driver (RS422)
Supply Voltage	4.75…30 V DC
Max Speed	6000 rpm
IP Rating	IP65
Housing Material	Aluminum alloy
Operating Temperature	-20℃~+70℃
Feature	1024ppr, solid shaft, M12 8pin connector, stable RS422 signal, shock resistant, compact aluminum housing
Certification	CE
Condition	New Original
MOQ	1 Piece
Gross Weight	0.30 KG
Net Weight	0.25 KG
Place of Origin	Germany
