Festo Pneumatic Silencer

属性名称	属性值
Brand	Festo
Model	U-1/8-B
Part No.	6841
Product Type	Pneumatic Silencer
Connection Thread	G1/8
Max Operating Pressure	0~1 MPa (0~10 bar)
Flow Rate to Atmosphere	680 l/min
Sound Pressure Level	80 dB(A)
Ambient Temperature	-10 ~70 ℃
Housing Material	Aluminum
Insert Material	PE
Medium	Compressed Air ISO8573-1:2010 [7:-:-]
Assembly Position	Any
Net Weight	3 g
Certification	RoHS Compliant
Function	Reduce exhaust noise of pneumatic valves and cylinders
Condition	New Original

INQUIRY

Product Details

Product Tags

Product Overview

New Original Festo U-1/8-B Pneumatic Silencer, Part No.6841. This compact U-series air silencer is designed for exhaust noise reduction of pneumatic valves and cylinders. Equipped with G1/8 male thread, aluminum housing and PE silencing insert. Max flow rate reaches 680 l/min and noise can be reduced to 80dB(A). Small size and light weight only 3g, can be mounted at any position. RoHS compliant, widely used in mini pneumatic automation systems.

Item	Specification
Brand	Festo
Model	U-1/8-B
Part Number	6841
Product Type	Pneumatic Silencer
Connection	G1/8
Operating Pressure	0~1 MPa
Flow Rate	680 l/min
Sound Pressure Level	80 dB(A)
Ambient Temperature	-10 ~70 ℃
Housing Material	Aluminum
Insert Material	PE
Medium	Compressed Air
Net Weight	3 g
Condition	New Original
