Festo pneumatic muffler

属性名称	属性值
Brand	Festo
Model	U-1/4-B
Part No.	6842
Product Type	Pneumatic Silencer
Pneumatic Connection	G1/4
Max Operating Pressure	0~1 MPa (0~10 bar)
Flow Rate to Atmosphere	2440 l/min
Sound Pressure Level	80 dB(A)
Ambient Temperature	-10 ~ 70 ℃
Housing Material	Aluminum
Insert Material	PE
Medium	Compressed Air ISO8573-1:2010 [7:-:-]
Assembly Position	Any
Weight	17 g
Certification	RoHS Compliant
Condition	New Original
Application	Pneumatic Exhaust Noise Reduction

INQUIRY

Product Details

Product Tags

Product Overview

New Original Festo Pneumatic Silencer Model U-1/4-B, Part No.6842. This air exhaust silencer is used to reduce exhaust noise from pneumatic valves and air cylinders. It comes with G1/4 male thread, aluminum housing and PE insert. The maximum flow rate can reach 2440 l/min, effectively lowering exhaust noise in pneumatic systems. It features compact size, stable performance and RoHS compliance, suitable for various industrial automation equipment.

Item	Specification
Brand	Festo
Model	U-1/4-B
Part Number	6842
Product Type	Pneumatic Silencer
Connection	G1/4
Max Operating Pressure	0~1 MPa
Flow Rate	2440 l/min
Sound Pressure Level	80 dB(A)
Ambient Temperature	-10 ~ 70 ℃
Housing Material	Aluminum
Insert Material	PE
Medium	Compressed Air
Net Weight	17 g
Condition	New Original
