337336 RS -3-1/8
Product Overview
Item No: 337336 Model: RS-3-1/8 Brand: Festo Type: Roller Lever Mechanical Valve
Festo RS-3-1/8 roller lever mechanical valve (337336) is 3/2-way normally closed monostable pneumatic limit valve. It adopts roller lever mechanical actuation and spring return. When the roller is touched by mechanical cam, the valve switches air circuit automatically. G1/8 three ports, compact structure, easy mounting with through holes. It is commonly used for stroke position signal feedback of cylinders on automation lines.
| 属性名称 | 属性值 |
|---|---|
| Brand | Festo |
| Model | RS-3-1/8 |
| Part No. | 337336 |
| Type | Roller Lever Mechanical Valve |
| Series | RS |
| Valve Function | 3/2-way, Normally Closed, Monostable |
| Actuation | Mechanical roller lever actuation |
| Reset Method | Mechanical spring return |
| Port Size | G1/8 |
| Nominal Width | 3.5 mm |
| Nominal Flow Rate | 151 l/min |
| Working Pressure | 0.35 ~ 0.8 MPa (3.5 ~ 8 bar) |
| Medium | Compressed air ISO 8573-1:2010 [-:-:-] |
| Ambient Temperature | -10 ~ +60 ℃ |
| Material | Anodized aluminum housing, NBR seal |
| Feature | Poppet seat, adjustable exhaust, internal pilot supply, CRC2 |
| Mounting | Through-hole mounting, any mounting position |
| Weight | 104 g |
| Condition | New Original |
