GR-QS-6

属性名称	属性值
Brand	Festo
Model	GR-QS-6
Part Number	193969
Product Type	One-way Flow Control Valve / Throttle Check Valve
Series	GR Series
Pneumatic Connection	QS-6, push-in for tubing OD 6mm
Flow rate (control direction)	245 l/min
Flow rate (free non-return direction)	430 l/min
Operating Pressure	0.2 ~ 10 bar
Medium	Compressed air ISO 8573-1:2010 [7:4:4]
Ambient Temperature	-10 ~ +60 ℃
Medium Temperature	-10 ~ +60 ℃
Adjustment Element	Knurled screw
Mounting	Any mounting position, optio

Product Details

Product Tags

Product Overview

Festo GR-QS-6 (Part No.193969) is GR series in-line one-way flow control valve, also known as throttle check valve. It can adjust airflow in one direction while offering free flow in reverse direction, widely used to regulate cylinder moving speed in pneumatic circuits. Quick push-in fitting for 6mm outer diameter air tube.

属性名称属性值
BrandFesto
ModelGR-QS-6
Part Number193969
Product TypeOne-way Flow Control Valve / Throttle Check Valve
SeriesGR Series
Pneumatic ConnectionQS-6, push-in for tubing OD 6mm
Flow rate (control direction)245 l/min
Flow rate (free non-return direction)430 l/min
Operating Pressure0.2 ~ 10 bar
MediumCompressed air ISO 8573-1:2010 [7:4:4]
Ambient Temperature-10 ~ +60 ℃
Medium Temperature-10 ~ +60 ℃
Adjustment ElementKnurled screw
MountingAny mounting position, optional panel mounting with accessories
Housing MaterialPA reinforced plastic
Seal MaterialNBR
Release RingPOM
Adjusting ScrewHigh alloy steel
Weight22 g
CRC ClassCRC 2
LABS(PWIS)VDMA24364-B1/B2-L
RoHSCompliant
Original/NewNew Original
