MS4-FRM-1/4-AD12

MS4-FRM-1/4-AD12
属性名称	属性值
Brand	Festo
Model	MS4-FRM-1/4-AD12
Part Number	527703
Product Type	Branching Module / Air Distributor Module
Series	MS4 Series
Grid Size	40 mm
Pneumatic Port	G1/4 female thread
Nominal Flow	4600 l/min
Operating Pressure	0 ~ 14 bar
Medium	Compressed air ISO 8573-1:2010 [7:4:4], inert gas
Pressure Sensor	LCD display, IO-Link, M8 4-pin plug
Sensor Output	PNP/NPN, analog 0-10V / 1-5V / 4-20mA
Ambient Temperature	-10 ~ +60 ℃
Medium Temperature	-10 ~ +60 ℃
Housing Material	Die-

Product Details

Product Tags

Product Overview

Festo MS4-FRM-1/4-AD12 (Part No.527703) is MS4 series compressed air branching module with built-in IO-Link pressure sensor and LCD display. It serves as intermediate air distributor for air preparation unit, with upper and lower air outlets, 40mm grid size, high flow rate and digital pressure monitoring function for modern smart pneumatic systems.

属性名称属性值
BrandFesto
ModelMS4-FRM-1/4-AD12
Part Number527703
Product TypeBranching Module / Air Distributor Module
SeriesMS4 Series
Grid Size40 mm
Pneumatic PortG1/4 female thread
Nominal Flow4600 l/min
Operating Pressure0 ~ 14 bar
MediumCompressed air ISO 8573-1:2010 [7:4:4], inert gas
Pressure SensorLCD display, IO-Link, M8 4-pin plug
Sensor OutputPNP/NPN, analog 0-10V / 1-5V / 4-20mA
Ambient Temperature-10 ~ +60 ℃
Medium Temperature-10 ~ +60 ℃
Housing MaterialDie-cast aluminium
Seal MaterialNBR
Weight165 g
MountingOptional mounting position
CRC ClassCRC 2
LABS(PWIS)VDMA24364-B1/B2-L
CertificationCE, UKCA
RoHSCompliant
Original/NewNew Original
