QSM-4-3
Product Overview
QSM-4-3, Part No.153078, belongs to Festo QS series mini push-in fitting. It is a tiny straight connector with M3 male thread on one side and quick insert port for 4mm outer diameter pneumatic tube on the other. Compact mini size specially designed for miniature pneumatic components. Tube can be directly inserted; press release ring to pull out tube without tools. Widely used for micro pneumatic control circuit of small cylinder, miniature solenoid valve and tiny fixture.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | QSM-4-3 |
| Part No. | 153078 |
| Type | Straight mini push-in fitting, male thread |
| Thread | M3 male thread |
| Tube OD | 4 mm |
| Nominal bore | 2.5 mm |
| Working medium | Compressed air |
| Working pressure | -0.95 ~14 bar |
| Temperature range | -10 ~ 80 ℃ |
| Material | Body:PBT,Stud:Nickel-plated brass,Release ring:POM,Seal:NBR,Tube retainer:High-alloy stainless steel |
| Weight | 1.20 g |
| Package | 10 pcs/pack |
| Feature | Mini compact structure, M3 male thread, push-pull quick connection, tool-free tube assembly and disassembly |
| RoHS | Compliant |
| Corrosion resistance class | CRC1 |
