WTB12F-24161220A00ZDZZZZZZZZZ1
Product Details
The SICK WTB12F-24161220A00ZDZZZZZZZZZ1 is a brand-new original diffuse reflection photoelectric sensor from the W12 series. It is equipped with visible red LED light source and operates within 10–30 V DC power supply, featuring PNP output and switchable Light-ON / Dark-ON function for easy integration with various industrial PLC control systems. It has IP67 protection grade and supports an ultra-wide working temperature range from -40℃ to +60℃, delivering stable performance in harsh industrial environments.
Constructed with robust zinc die-cast rectangular metal housing, this sensor uses M12 4-pin connector for quick installation and wiring. It identifies objects by capturing light reflected directly from target surfaces and requires no additional reflector.
This sensor is widely used for object detection on packaging machinery, conveyor belts and material handling automated production lines. Each unit undergoes strict pre-shipment quality inspection and holds CE certification. We supply genuine SICK sensors with MOQ of 1 piece and provide stable global shipping services to meet your factory automation demands.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | WTB12F-24161220A00ZDZZZZZZZZZ1 |
| Product Name | Photoelectric Sensor |
| Product Type | Diffuse Reflection Photoelectric Sensor |
| Series | W12 Series |
| Working Principle | Diffuse reflection detection |
| Light Source | Visible Red LED |
| Housing Material | Zinc die-cast metal |
| Shape | Rectangular |
| Dimension(W×H×D) | 15.8mm × 49.2mm × 43.1mm |
| Connection | M12 4-pin connector |
| Output Type | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | 10 … 30 V DC |
| IP Rating | IP67 |
| Ambient Temperature | -40℃ ~ +60℃ |
| Net Weight | 0.22 kg |
| Gross Weight | 0.27 kg |
| Origin | Germany |
| Condition | Brand New Original |
| Application | Object detection, packaging machinery, conveyor automation, material handling |
| Certificate | CE |
| MOQ | 1 Piece |
