1069579 GRTE18S-P2442
Product Overview
GRTE18S-P2442 (Part No.1069579) is a M18 cylindrical diffuse photoelectric sensor with background suppression from SICK GRTE18S series. It adopts PinPoint 620nm visible red LED light source, sensing distance ranges from 10 mm to 1000 mm. Equipped with a 5-turn potentiometer for sensitivity adjustment, it comes with PNP output supporting switchable Light-ON / Dark-ON mode. Fitted with 2m fixed cable and M12 4-pin male connector. Made of cylindrical plastic housing with IP67 protection class and built-in visual LED working indicator. Thanks to background suppression technology, it can detect target objects reliably and avoid false triggering caused by background reflection. Brand new original SICK photoelectric sensor.
| 属性 | 属性 |
|---|---|
| Brand | SICK |
| Model Number | GRTE18S-P2442 |
| Part No. | 1069579 |
| Product Type | Photoelectric Sensor |
| Series | G18 / GRTE18S |
| Detection principle | Diffuse photoelectric sensor with background suppression |
| Light Source | PinPoint red LED, 620nm visible red light |
| Sensing Distance | 10 ~ 1000 mm |
| Adjustment | 5-turn potentiometer |
| Output | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | DC10 ~ 30 V |
| Connector | M12 4-pin male connector, 2m fixed cable |
| Housing | M18 cylindrical plastic housing |
| Protection Class | IP67 |
| Switching Frequency | 500 Hz |
| Special Feature | M18 cylindrical design, background suppression, visual LED indicator, easy alignment |
| Condition | New Original |
| Application | Object detection, packaging machinery, conveyor systems, material handling equipment |
| Net Weight | 0.045 KG |
| Gross Weight | 0.075 KG |
| Place of Origin | Germany |
| MOQ | 1 Piece |
| Warranty | 12 Months |
