1064694 GTB10-P4211
Product Overview
GTB10-P4211 (Part No.1064694) is a compact rectangular diffuse photoelectric sensor with background suppression from SICK GTB10 series. It uses PinPoint 625nm visible red LED light source, sensing distance ranges from 20 mm to 950 mm. Equipped with a 5-turn potentiometer for sensitivity adjustment, it provides PNP output with switchable Light-ON / Dark-ON function. It comes with M12 4-pin male connector, rectangular plastic housing of size 20×50×39mm, IP67 protection class and built-in visible LED working indicator. The response time ≤500µs, stable for object detection. It is widely used in packaging machinery, conveyor systems and material handling equipment. Brand new original SICK photoelectric sensor.
| 属性 | 属性值 |
|---|---|
| Brand | SICK |
| Model Number | GTB10-P4211 |
| Part No. | 1064694 |
| Product Type | Photoelectric Sensor |
| Series | G10 / GTB10 |
| Detection principle | Diffuse photoelectric sensor with background suppression |
| Light Source | PinPoint red LED, 625nm visible red light |
| Sensing Distance | 20 ~ 950 mm |
| Adjustment | 5-turn potentiometer for sensitivity setting |
| Output | PNP, Light-ON / Dark-ON switchable |
| Supply Voltage | DC10 ~ 30 V |
| Connector | M12 4-pin male connector |
| Housing | Rectangular plastic housing, size 20×50×39mm |
| Protection Class | IP67 |
| Response Time | ≤500µs |
| Special Feature | Compact rectangular design, PinPoint precise light spot, background suppression, visible LED indicator |
| Condition | New Original |
| Application | Object detection, packaging machinery, conveyor systems, material handling equipment |
| Net Weight | 0.035 KG |
| Gross Weight | 0.063 KG |
| Place of Origin | Germany |
| MOQ | 1 Piece |
| Warranty | 12 Months |
