1078167 KTX-WS91141242ZZZZ
Product Overview
KTX-WS91141242ZZZZ (Part No.1078167) is a high-performance color mark sensor from SICK KTX series. Equipped with RGB multi-color LED light source, it detects objects by color contrast principle, fixed sensing distance of 12 mm. It integrates BluePilot teach-in function for convenient on-site configuration, supports Push-pull (NPN/PNP) dual output and IO-Link communication interface. The zinc diecast metal housing features IP67 protection class, M12 4-pin male connector and DC10~30V power supply. It is widely used for color mark detection and label positioning in packaging and printing converting automation. Brand new original SICK color mark sensor.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model Number | KTX-WS91141242ZZZZ |
| Part No. | 1078167 |
| Product Type | Color Mark Sensor |
| Series | KTX |
| Principle | Color contrast detection |
| Light Source | RGB multi-color LED |
| Adjustment | BluePilot, teach-in function |
| Output Type | Push-pull (NPN/PNP) |
| Supply Voltage | 10 V DC ~ 30 V DC |
| Interface | IO-Link |
| Housing Material | Zinc diecast metal |
| Protection Class | IP67 |
| Sensing Distance | 12 mm |
| Connector | M12 4-pin male connector |
| Condition | New Original |
| Application | Printing mark detection, packaging machinery, label positioning, printing & converting industry |
| Net Weight | 0.070 KG |
| Gross Weight | 0.102 KG |
| Place of Origin | Germany |
| MOQ | 1 Piece |
| Warranty | 12 Months |
