5755 VZ-3-PK-3
Product Overview
Item No: 5755
Model: VZ-3-PK-3
Brand: Festo
Type: Adjustable Pneumatic Time Delay Valve, VZ Series
| 属性名称 (Key) | 属性值 (Value) |
|---|---|
| Brand | Festo |
| Model | VZ-3-PK-3 |
| Part No. | 5755 |
| Product Series | VZ |
| Product Type | Pneumatic Time Delay Valve |
| Valve Function | On-delay pneumatic timing valve |
| Pneumatic Connection | PK-3 (3mm tube push-in fitting) |
| Nominal Diameter | 2 mm |
| Nominal Flow Rate | 90 l/min |
| Operating Pressure | 2.5 ~ 8 bar |
| Adjustable Delay Time | 0.25 s ~ 5 s |
| Reset Pause Time | ≥55 ms |
| Time Repeat Accuracy | ±0.5 s |
| Operating Medium | Filtered compressed air ISO 8573-1 [7:4:4], non-lubricated only |
| Ambient Temperature | -10 ℃ ~ +60 ℃ |
| Housing Material | Die-cast zinc |
| Seal Material | NBR |
| Reset Type | Mechanical spring |
| Mounting | Panel mounting / mounting frame installation |
| Net Weight | 150 g/pc |
| RoHS Compliance | Yes |
| Feature | Adjustable pneumatic time delay, poppet valve with spring return |
| Application | Pneumatic circuit timing control, automation machine sequence control |
