577257 VSNC-FC-M52-MD-G14-F8
Product Overview
Item No: 577257 Model: VSNC-FC-M52-MD-G14-F8 Brand: Festo Type: 5/2-Way Bistable Double Pilot Solenoid Valve
Festo VSNC-FC-M52-MD-G14-F8 solenoid valve (577257) belongs to VSNC robust directional valve series. It is a 5/2-way double pilot bistable valve. The valve keeps its switching state after removing electric signal without continuous power supply. MD manual override button allows manual testing during machine commissioning. G1/4 threaded port with large flow capacity, mounted on separate sub-base, easy maintenance. Mainly controls double acting cylinders on automated machines.
| 属性名称 | 属性值 |
|---|---|
| Brand | Festo |
| Model | VSNC-FC-M52-MD-G14-F8 |
| Part No. | 577257 |
| Type | Solenoid Valve / Directional Control Valve |
| Series | VSNC |
| Valve Function | 5/2-way, double pilot, bistable |
| Coil Voltage | DC24V |
| Port Size | G1/4 |
| Working Pressure | 0.2 ~ 1.0 MPa (2 ~ 10 bar) |
| Nominal Flow Rate | 1100 l/min |
| Medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Ambient Temperature | -10 ~ +50 ℃ |
| Material | Valve body: Aluminum alloy; Seals: NBR |
| Feature | FC sub-base mounting; M52 5/2 bistable; MD manual override; G1/4 port; F8 coil, high flow |
| Mounting | Sub-base installation |
| Protection Class | IP65 (with connector) |
| Condition | New Original |
