CQF16-06EPOEP1 6068625

属性名	属性值
Brand	SICK
Model	CQF16-06EPOEP1
Part No.	6068625
Series	CQF16
Sensor type	Capacitive proximity sensor
Sensing distance	0.5 ~ 6 mm
Installation	Non-flush mount
Output type	PNP, NC
Wiring	DC 3-wire
Connection	M8 male, 3-pin, 0.3m cable
Supply voltage	10–30 V DC
Max switching current	100 mA
Switching frequency	80 Hz
IP rating	IP67
Housing material	PBT plastic
Operating temperature	-20 ℃ ~ +75 ℃
Feature	Compact flat design, sensitivity adjustable, anti-interference
Weight(n

INQUIRY

Product Details

Product Tags

Product Overview

New original SICK CQF16-06EPOEP1 capacitive proximity sensor, PN 6068625, flat rectangular CQF16 series sensor. Sensing range 0.5~6mm, PNP NC output, 10-30VDC power supply. It comes with 0.3m cable and M8 3-pin male connector with IP67 protection grade. PBT plastic housing, compact flat structure for low-profile installation. Stable anti-interference performance within -20℃ ~ +75℃. Suitable for material level detection and object sensing in narrow installation space on packaging and conveyor automation lines. We supply genuine SICK sensors with fast delivery and professional after-sales support.

属性名	属性值
Brand	SICK
Model	CQF16-06EPOEP1
Part No.	6068625
Series	CQF16
Sensor type	Capacitive proximity sensor
Sensing distance	0.5 ~ 6 mm
Installation	Non-flush mount
Output type	PNP, NC
Wiring	DC 3-wire
Connection	M8 male, 3-pin, 0.3m cable
Supply voltage	10–30 V DC
Max switching current	100 mA
Switching frequency	80 Hz
IP rating	IP67
Housing material	PBT plastic
Operating temperature	-20 ℃ ~ +75 ℃
Feature	Compact flat design, sensitivity adjustable, anti-interference
Weight(net)	0.04 kg
Weight(gross)	0.09 kg
Certificate	RoHS
