VAS-55-1/4-PUR-B
Product Overview
VAS-55-1/4-PUR-B, Part No.1396095, belongs to Festo VAS series flat vacuum suction cup. Round flat shape with 55mm diameter and G1/4 top vacuum thread. Made of durable PUR polyurethane material, equipped with built-in 3.5mm height compensator to compensate minor workpiece unevenness. LABS/PWIS compliant, suitable for paint shop and coating lines. Widely used for robotic vacuum handling of flat workpieces.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | VAS-55-1/4-PUR-B |
| Part No. | 1396095 |
| Type | Flat vacuum suction cup, VAS series |
| Suction cup diameter | 55 mm |
| Vacuum port | G1/4 male thread, top connection |
| Nominal bore | 4 mm |
| Effective suction diameter | 44.7 mm |
| Suction cup volume | 8.01 cm³ |
| Holding force @ -0.7 bar | 110 N |
| Working medium | Atmospheric air ISO 8573-1:2010 [7:-:-] |
| Working pressure | -0.95 ~ 0 bar |
| Nominal vacuum pressure | -0.7 bar |
| Temperature range | -20 ~ 60 ℃ |
| Material | Suction cup: PUR polyurethane, screw insert: die-cast zinc |
| Hardness | Shore A 60 ±5 |
| Color | Blue |
| Weight | 30.00 g |
| Feature | 3.5mm height compensator, LABS/PWIS compliant, flat round shape |
| Corrosion resistance class | CRC2 |
| RoHS | Compliant |
| Standard | VDMA24364-A1-L |
