1036928 DFS60B-TJPK10000
Product Overview
DFS60B-TJPK10000, Order No.1036928, is SICK incremental rotary encoder. It delivers 10000 ppr high resolution, fitted with 10mm solid shaft and 8-pin M12 straight connector. It uses RS422 line driver output, supply voltage 4.75~30V DC, maximum rotating speed up to 6000 rpm. Aluminum alloy housing with IP65 protection. It has excellent shock resistance and anti-interference performance, stable signal transmission, widely applied for high-precision speed and position feedback of industrial motion control systems.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | DFS60B-TJPK10000 |
| Order No. | 1036928 |
| Product Type | Incremental Rotary Encoder |
| Connector Type | M12 Straight, 8 Pin |
| Pin | 8 Pin |
| Pulse Per Revolution | 10000 ppr |
| Shaft Type | Solid shaft |
| Shaft Diameter | 10 mm |
| Output Signal | Line driver (RS422) |
| Supply Voltage | 4.75…30 V DC |
| Max Speed | 6000 rpm |
| IP Rating | IP65 |
| Housing Material | Aluminum alloy |
| Operating Temperature | -20℃~+70℃ |
| Feature | High resolution, solid shaft, anti-interference, shock resistant, stable RS422 signal |
| Certification | CE |
| Condition | New Original |
| MOQ | 1 Piece |
| Gross Weight | 0.30 KG |
| Net Weight | 0.25 KG |
| Place of Origin | Germany |
