DFS60B-S4AL05000

属性名称	属性值
Brand	SICK
Model	DFS60B-S4AL05000
Product Type	Incremental Rotary Encoder
Connector Type	M12 Straight, 8 Pin
Pin	8 Pin
Pulse Per Revolution	5000 ppr
Shaft Type	Solid shaft
Shaft Diameter	10 mm
Output Signal	Line driver (RS422)
Supply Voltage	4.75…30 V DC
Max Speed	6000 rpm
IP Rating	IP65
Housing Material	Aluminum alloy
Operating Temperature	-20℃~+70℃
Feature	5000ppr high resolution, solid shaft, stable RS422 signal, anti-vibration, compact aluminum housing
Certification

INQUIRY

Product Details

Product Tags

Product Overview

DFS60B-S4AL05000 is SICK incremental rotary encoder. It comes with 5000 ppr resolution, 10mm solid shaft and 8-pin M12 straight connector. Equipped with RS422 line driver output, supply voltage ranges from 4.75 to 30V DC, max rotating speed reaches 6000 rpm. Aluminum alloy housing with IP65 protection grade. Featuring anti-vibration performance and stable signal transmission, it provides reliable speed and position feedback for industrial motion control.

属性名称	属性值
Brand	SICK
Model	DFS60B-S4AL05000
Product Type	Incremental Rotary Encoder
Connector Type	M12 Straight, 8 Pin
Pin	8 Pin
Pulse Per Revolution	5000 ppr
Shaft Type	Solid shaft
Shaft Diameter	10 mm
Output Signal	Line driver (RS422)
Supply Voltage	4.75…30 V DC
Max Speed	6000 rpm
IP Rating	IP65
Housing Material	Aluminum alloy
Operating Temperature	-20℃~+70℃
Feature	5000ppr high resolution, solid shaft, stable RS422 signal, anti-vibration, compact aluminum housing
Certification	CE
Condition	New Original
MOQ	1 Piece
Gross Weight	0.30 KG
Net Weight	0.25 KG
Place of Origin	Germany
