GRE-1/8
Product Overview
GRE-1/8, Part No.3646, belongs to Festo GRE series one-way flow control valve. It is exhaust type throttle valve with G1/8 thread. When cylinder extends or retracts, the exhaust air flows through adjustable throttle to realize speed control; supply air can pass through built-in check valve without restriction. Simple structure, compact nickel-plated brass body, convenient to mount directly on cylinder port. Widely used to adjust the moving speed of small pneumatic cylinders in automation equipment.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | GRE-1/8 |
| Part No. | 3646 |
| Type | One-way flow control valve, exhaust throttling |
| Pneumatic port | G1/8 |
| Operating pressure | 0.1 ~ 10 bar |
| Working medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Temperature range | -10 ~ 60 ℃ |
| Material | Body: Brass nickel-plated, Seal: NBR |
| Weight | 10.00 g |
| Feature | Exhaust air throttling, adjustable flow rate, built-in check valve, compact brass body, easy speed regulation for cylinder |
| RoHS | Compliant |
| Corrosion resistance class | CRC2 |
