6DL1136-6BA00-0PH1

Attribute Name	Value
Brand	Siemens
Model	6DL1136-6BA00-0PH1
Series	SIMATIC ET200SP HA, F-DI Fail-safe Digital Input Module
Type	Fail-safe Digital Input Module
I/O Spec	F-DI 16×DC24V HA, 16-channel safety digital input
Safety Level	SIL3 (IEC61508), up to PL E (ISO13849-1)
Power Supply	DC24V (19.2V~28.8V), reverse polarity protection
Sensor Supply	Max 0.5A per channel, total max 8A, short-circuit protection
Feature	Channel-level diagnosis, IO redundancy support, 10ms high-precision timest

INQUIRY

Product Details

Product Tags

Product Overview

Siemens 6DL1136-6BA00-0PH1 is ET200SP HA F-DI 16×24VDC HA fail-safe digital input module. It is a safety I/O module for PROFINET distributed station, certified SIL3 (IEC61508) and up to PL E (ISO13849-1). It provides 16 channels DC24V safety digital input with channel diagnosis, supports IO redundancy and high-precision 10ms timestamp. With short-circuit protected sensor power supply. Powered by DC24V, DIN rail mounted on ET200SP HA station, matched with H1/M1 base unit. Widely used in SIS safety instrumented systems for chemical, petrochemical and power industry.

Attribute Name	Value
Brand	Siemens
Model	6DL1136-6BA00-0PH1
Series	SIMATIC ET200SP HA, F-DI Fail-safe Digital Input Module
Type	Fail-safe Digital Input Module
I/O Spec	F-DI 16×DC24V HA, 16-channel safety digital input
Safety Level	SIL3 (IEC61508), up to PL E (ISO13849-1)
Power Supply	DC24V (19.2V~28.8V), reverse polarity protection
Sensor Supply	Max 0.5A per channel, total max 8A, short-circuit protection
Feature	Channel-level diagnosis, IO redundancy support, 10ms high-precision timestamp
Base Unit	H1/M1 terminal base, color code CC01
Mounting	DIN rail, ET200SP HA distributed IO station
Origin	Germany
Warranty	1 year
Condition	New Original
Net Weight	0.30kg
Gross Weight	0.48kg
