6ES7360-3AA01-0AA0
Product Overview
Siemens 6ES7360-3AA01-0AA0 is IM360 transmitter interface module for SIMATIC S7-300 PLC system. It is mounted on the main rack and transmits backplane bus signals to IM361 receiver module via dedicated extension cable. The maximum extension distance is 5 meters. Powered by DC24V, max backplane bus current consumption 0.8A, DIN rail installation on S7-300 main rack. It is used together with IM361 to realize multi-rack expansion of S7-300 PLC for adding extra IO modules.
| Attribute Name | Value |
|---|---|
| Brand | Siemens |
| Model | 6ES7360-3AA01-0AA0 |
| Series | SIMATIC S7-300, IM360 Interface Module |
| Type | PLC Interface Module |
| Function | Transmitter module on S7-300 main rack, send backplane signal to IM361 |
| Matching Module | Work with IM361 (6ES7361-3CA01-0AA0) |
| Max. Extension Distance | 5m (with dedicated extension cable) |
| Power Supply | DC24V |
| Backplane Bus Current Consumption | Max 0.8A |
| Mounting | DIN rail, S7-300 main backplane |
| Origin | Germany |
| Warranty | 1 year |
| Condition | New Original |
| Net Weight | 0.28kg |
| Gross Weight | 0.45kg |
