ATV930D37N4

ATV930D37N4
Attribute Name	Value
Brand	Schneider Electric
Model	ATV930D37N4
Series	Altivar Process ATV930
Type	Variable Speed Drive / VFD
Motor Power	37kW Normal duty,30kW Heavy duty
Rated Voltage	380~480V 3Phase
Output Current	74.5A(Normal),66.2A(Heavy)
IP Rating	IP21
Built-in Brake Unit	Yes
Cooling	Forced convection
Communication	Modbus TCP,Modbus RTU,EtherNet/IP
Condition	New Original
Net Weight	28.20kg
Gross Weight	37.80kg

Product Details

Product Tags

Product Overview

Schneider ATV930D37N4 belongs to Altivar Process ATV930 series, high-performance industrial variable speed drive for process industry. This 3-phase 380~480V VFD supports asynchronous motors and synchronous reluctance motors. It adopts IP21 protection grade with integrated braking chopper, equipped with STO and SS1 safety functions. With built-in energy monitoring and asset monitoring, it realizes predictive maintenance and energy saving, ideal for pumps, fans, compressors and conveyors in process control applications.

Attribute NameValue
BrandSchneider Electric
ModelATV930D37N4
SeriesAltivar Process ATV930
TypeVariable Speed Drive / VFD
Motor Power37kW Normal duty,30kW Heavy duty
Rated Voltage380~480V 3Phase
Output Current74.5A(Normal),66.2A(Heavy)
IP RatingIP21
Built-in Brake UnitYes
CoolingForced convection
CommunicationModbus TCP,Modbus RTU,EtherNet/IP
ConditionNew Original
Net Weight28.20kg
Gross Weight37.80kg
