PUN-H-4X0,75-SI
Product Overview
New Original FESTO PUN-H-4X0,75-SI belongs to PUN-H flexible PU plastic tubing series. Outer diameter 4mm, wall thickness 0.75mm, inner diameter 2.6mm, translucent blue color. Made of ether-based TPE-U polyurethane material, hydrolysis and microbe resistant, suitable for energy chain high-cycle moving applications. Operating pressure -0.95~10 bar, ambient temperature -35~60℃. LABS(PWIS) compliant VDMA24364-B2-L, F1a grade for lithium battery production. Widely used for compressed air, vacuum and ice-free water pipeline in lithium battery, packaging and paint workshop automation.
| 属性名称 | 属性值 |
|---|---|
| Brand | FESTO |
| Model | PUN-H-4X0,75-SI |
| Order No. | 558278 |
| Product Series | PUN-H |
| Product Type | Flexible PU plastic pneumatic tubing |
| Outer diameter | 4 mm |
| Wall thickness | 0.75 mm |
| Inner diameter | 2.6 mm |
| Color | Translucent blue (SI) |
| Operating pressure | -0.95 ~10 bar (temperature dependent) |
| Min. bending radius | 8 mm |
| Flow-relevant bending radius | 16 mm |
| Ambient Temperature | -35 ~ +60 ℃ |
| Medium | Compressed air ISO 8573-1:2010 [7:-:-], ice-free water |
| Tubing material | TPE-U (PU) ether based |
| Fire rating | UL94 HB |
| Feature | LABS(PWIS) compliant VDMA24364-B2-L；Hydrolysis & microbe resistant；Suitable for energy chain, high cycle movement；Translucent blue, flexible and kink-proof；F1a grade for lithium battery production |
| Matching fitting | Push-in fitting for OD4mm tube |
| Corrosion Resistance Class | CRC2 |
| Weight | 0.0085 kg/m |
| Certificate | TÜV, RoHS |
| Origin | Germany |
| Condition | New Original |
