EV-20/120-5

属性名称	属性值
Brand	Festo
Model	EV-20/120-5
Part No	13292
Product Type	Diaphragm Clamping Module / Clamping Cylinder
Series	EV Series
Operation Mode	Single-acting, spring reset
Stroke	5 mm
Clamping Surface	20 × 120 mm
Pneumatic Port	M5
Operating Pressure	0.2 ~ 0.6 MPa (2 ~ 6 bar)
Medium	Compressed air ISO 8573-1:2010 [7:-:-]
Ambient Temperature	-20 ~ +40 ℃
Mounting	Through-hole mounting, any mounting position
Housing Material	Die-cast Aluminium
Diaphragm Material	TPE-U(PU)
Weight	190.

INQUIRY

Product Details

Product Tags

Product Description

Festo EV-20/120-5 (Part No.13292) is EV series diaphragm clamping module, also known as membrane clamping cylinder. It is single-acting with spring reset, short stroke 5 mm and 20×120 mm clamping area.

The flat compact design fits narrow installation space. Adopt hermetically sealed diaphragm structure, effectively prevent dust from entering. M5 air port, working pressure 2~6 bar. Free of copper and PTFE, specially suitable for lithium battery manufacturing lines. It generates high clamping force for workpiece holding in automation fixtures.

Item	Specification
Brand	Festo
Model	EV-20/120-5
Part Number	13292
Type	Diaphragm clamping module
Series	EV
Operation	Single-acting, spring reset
Stroke	5 mm
Clamping Surface	20 ×120 mm
Pneumatic Port	M5
Operating Pressure	0.2 ~0.6 MPa
Medium	Compressed air ISO 8573-1 [7:-:-]
Ambient Temp	-20 ~ +40 ℃
Weight	190.00 g
Material	Die-cast aluminium, TPE-U(PU) diaphragm
Corrosion Class	CRC1
Standard	LABS, RoHS, Copper & PTFE free
