GRO-1/8-B
Product Description
Festo GRO-1/8-B (Part No.15118) is GRO series pneumatic rotary union. It is a straight rotary fitting with G1/8 male thread on one side and G1/8 female thread on the other side. It enables 360° continuous rotation of pneumatic pipeline, maximum rotational speed 500 rpm with low friction torque.
Nominal width 4 mm, working pressure -0.095~1.0 MPa, suitable for compressed air. Nickel-plated brass housing and NBR sealing ring, stable sealing performance during rotation. CRC1 corrosion resistance, LABS and RoHS compliant, ideal for rotary indexing tables and rotating automation pneumatic circuits.
| Item | Specification |
|---|---|
| Brand | Festo |
| Model | GRO-1/8-B |
| Part Number | 15118 |
| Type | Straight pneumatic rotary union |
| Port1 | G1/8 Male Thread |
| Port2 | G1/8 Female Thread |
| Nominal Width | 4 mm |
| Operating Pressure | -0.095 ~1.0 MPa |
| Ambient Temp | -10 ~ +60 ℃ |
| Max Rotational Speed | 500 rpm |
| Weight | 28.00 g |
| Material | Nickel-plated brass, NBR seal |
| Corrosion Class | CRC1 |
| Standard | LABS, RoHS |
