MICS3-ABAZ40PZ1P01
Product Overview
MICS3-ABAZ40PZ1P01 is SICK microScan3 Core safety laser scanner, order number 1100404. It adopts 275° wide scanning angle, with 4m protective field and 40m warning field. It supports PROFINET & PROFIsafe safety bus communication, and provides 8 freely configurable safety fields. Equipped with bottom M12 system plug, 24V DC power supply. Aluminum alloy housing with IP65 protection class. Compact and stable, it is widely applied for area protection, AGV anti-collision and machinery safety guarding.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | MICS3-ABAZ40PZ1P01 |
| Order No. | 1100404 |
| Product Type | Safety Laser Scanner |
| Series | microScan3 Core |
| Communication | PROFINET / PROFIsafe |
| Protective Field Range | 4 m |
| Warning Field Range | 40 m |
| Scan Angle | 275° |
| Configurable Safety Fields | 8 safety fields |
| Connection | M12 system plug, pre-mounted on bottom |
| Supply Voltage | 24 V DC |
| Housing Material | Aluminum alloy |
| IP Rating | IP65 |
| Operating Temperature | -10℃~+50℃ |
| Feature | microScan3 safety laser scanner,PROFINET PROFIsafe,275° scanning angle,4m protective range,8 configurable safety fields,indoor use,compact design,multi-zone protection for AGV & machine guarding |
| Certification | CE |
| Condition | New Original |
| MOQ | 1 Piece |
| Gross Weight | 1.58 KG |
| Net Weight | 1.45 KG |
| Place of Origin | Germany |
