I200-M0413

属性名称	属性值
Brand	SICK
Model	I200-M0413
Order No.	1090411
Product Type	Safety non-contact magnetic sensor
Series	I200
Working Principle	Magnetic non-contact
Safety Output	2 OSSD safety outputs
Connection	M12 4-pin connector
Supply Voltage	24 V DC
Actuating Distance	13 mm
Housing Material	Plastic
Mounting	Surface mount
IP Rating	IP67
Operating Temperature	-25℃~+70℃
Feature	Compact magnetic safety sensor, 13mm actuation distance, 2OSSD outputs, IP67 waterproof, for safety gate & machin

INQUIRY

Product Details

Product Tags

Product Overview

I200-M0413 is SICK non-contact magnetic safety sensor, order number 1090411. It is I200 series safety sensor with 13mm actuating distance and 2 OSSD safety outputs, equipped with M12 4-pin connector, supply voltage 24V DC. Plastic housing with IP67 waterproof grade and surface mounting. Magnetic non-contact triggering realizes wear-free operation and long service life, widely used for safety gate and machine guard monitoring in machine safety interlock systems.

属性名称	属性值
Brand	SICK
Model	I200-M0413
Order No.	1090411
Product Type	Safety non-contact magnetic sensor
Series	I200
Working Principle	Magnetic non-contact
Safety Output	2 OSSD safety outputs
Connection	M12 4-pin connector
Supply Voltage	24 V DC
Actuating Distance	13 mm
Housing Material	Plastic
Mounting	Surface mount
IP Rating	IP67
Operating Temperature	-25℃~+70℃
Feature	Compact magnetic safety sensor, 13mm actuation distance, 2OSSD outputs, IP67 waterproof, for safety gate & machine guard monitoring, wear-free operation
Certification	CE
Condition	New Original
MOQ	1 Piece
Gross Weight	0.08 KG
Net Weight	0.06 KG
Place of Origin	Germany
