MPYE-5-M5-010-B
Product Overview
MPYE-5-M5-010-B (Part No.151694) is Festo MPYE series 5/3-way proportional directional valve. It receives 0~10V analog control signal to continuously adjust airflow direction and flow rate, realize stepless regulation of cylinder speed, position and output force. Mid-position closed, M5 pneumatic connection, nominal flow 100 l/min, excellent linearity and repeatability. Suitable for high-precision pneumatic closed-loop control systems.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | MPYE-5-M5-010-B |
| Part No. | 151694 |
| Product Type | Pneumatic Proportional Directional Control Valve, 5/3-way |
| Series | MPYE |
| Pneumatic Connection | M5 |
| Control Signal | 0 ~ 10 V DC |
| Supply Voltage | 24 V DC ±10% |
| Operating Pressure | 0 ~ 8 bar |
| Nominal Flow | 100 l/min |
| Hysteresis | ≤0.5 % FS |
| Repeatability | ≤0.5 % FS |
| Linearity | ≤1.5 % FS |
| Valve Function | 5/3-way, mid-position closed |
| Mounting | Any position |
| Operating Medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Ambient Temperature | 5 ~ +50 ℃ |
| Housing Material | Aluminium alloy, anodised |
| Seal Material | NBR |
| CRC Corrosion Class | CRC2 |
| LABS Compliance | VDMA24364-B1/B2-L |
| Net Weight | 0.160 kg |
| Gross Weight | 0.22 kg |
| RoHS | Compliant |
| Condition | New Original |
| Application | Proportional position / speed / force control, precision automation, test equipment, micro assembly |
