VPEV-1/8
Product Overview
VPEV-1/8, Part No.15012, belongs to Festo VPEV series compact single-stage vacuum ejector. It generates vacuum by Venturi effect using compressed air. Built-in silencer reduces exhaust noise. Small footprint design, directly connects to vacuum suction cups without extra vacuum reservoir. Suitable for short cycle and small workpiece pick & place applications in automated handling systems.
| 属性名 | 属性值 |
|---|---|
| Brand | Festo |
| Model | VPEV-1/8 |
| Part No. | 15012 |
| Type | Vacuum ejector, single stage |
| Port size | G1/8 |
| Nozzle diameter | 0.8 mm |
| Max vacuum | 85 % |
| Suction flow rate | 18 l/min |
| Supply air pressure | 4 ~ 6 bar |
| Working medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Temperature range | 5 ~ 50 ℃ |
| Material | Housing: POM, Seal: NBR |
| Weight | 18.00 g |
| Feature | Compact single-stage ejector, integrated silencer, no vacuum tank required, direct suction cup connection |
| Corrosion resistance class | CRC1 |
| RoHS | Compliant |
