130642 QSS-8-F
Product Overview
Item No: 130642 Model: QSS-8-F Brand: Festo Type: Push-in Pneumatic Fitting
Festo QSS-8-F push-in fitting (130642) belongs to QSS quick connector series. It is a straight female thread fitting for 8mm OD plastic tubing, with G1/4 internal thread. Push-in structure enables fast connection and disassembly of air pipes, no extra tools required. Excellent sealing performance for compressed air and vacuum lines, commonly used to connect pneumatic components such as cylinders, valves and air service units.
| 属性名称 | 属性值 |
|---|---|
| Brand | Festo |
| Model | QSS-8-F |
| Part No. | 130642 |
| Type | Push-in Fitting |
| Series | QSS |
| Tube Outer Diameter | 8 mm |
| Thread Type | Female thread G1/4 |
| Working Pressure | -0.095 ~ 1.0 MPa |
| Medium | Compressed air, vacuum |
| Ambient Temperature | -10 ~ +80 ℃ |
| Material | Body: Nickel-plated brass; Release ring: PA; Seal: NBR |
| Feature | Push-in quick connection, female straight fitting, easy assembly |
| Mounting | Pneumatic pipeline connection |
| Condition | New Original |
