CPE14-M1CH-5L-1/8
Product Overview
New Original FESTO CPE14-M1CH-5L-1/8 belongs to CPE14 compact performance solenoid valve series. It is a 5/2-way monostable single electric control valve, valve width 14mm with G1/8 pneumatic port, nominal flow rate up to 800 l/min, operating voltage 24V DC. Adopts piston gate valve structure with soft NBR seal, internal pilot air supply and pneumatic spring reset. Protection grade reaches IP65/IP67 when equipped with matching plug socket, operating pressure 3~8 bar. LABS(PWIS) compliant VDMA24364-B1/B2-L, suitable for lithium battery, packaging and paint workshop automation. Widely used for directional control of small pneumatic cylinders in valve islands and standalone pneumatic circuits.
| 属性名称 | 属性值 |
|---|---|
| Brand | FESTO |
| Model | CPE14-M1CH-5L-1/8 |
| Order No. | 550237 |
| Product Series | CPE14 |
| Product Type | Compact performance pneumatic solenoid valve |
| Valve Function | 5/2-way, monostable（二位五通单稳态，单电控） |
| Actuation | Pilot-controlled, electrical actuation |
| Width | 14 mm |
| Pneumatic Port | G1/8 |
| Nominal width | 6 mm |
| Nominal flow rate | 800 l/min |
| Operating Voltage | 24V DC |
| Operating pressure | 3 ~ 8 bar |
| Ambient Temperature | -10 ~ +60 ℃ |
| Protection class | IP65 / IP67 (with matching plug socket) |
| Medium | Compressed air ISO 8573-1:2010 [7:-:-] |
| Structure | Piston gate valve, soft sealing |
| Reset mode | Pneumatic spring reset |
| Pilot air supply | Internal pilot supply |
| Housing material | Die-cast aluminium alloy |
| Seal material | NBR |
| Feature | LABS (PWIS) compliant VDMA24364-B1/B2-L；14mm 窄宽度单电控电磁阀，内置先导，排气可调节，适配阀岛模块化安装 |
| Mounting | Any mounting position, mounting via through-holes |
| Corrosion Resistance Class | CRC2 |
| Weight | 110 g |
| Certificate | CE, cULus, DNV |
| Origin | Germany |
| Condition | New Original |
