CQF16-06EPSEW1 6068622
Product Overview
New original SICK CQF16-06EPSEW1 capacitive proximity sensor, Order No.6068622. This CQF16 series capacitive sensor adopts teach-in function principle, 0.5–6 mm sensing range, 0.01mm high resolution with PNP NO output signal. Equipped with 2m 4-core PVC cable and mounting bracket, protection grade IP67, IP68, IP69K. Wide temperature range -25℃~+80℃, anti-foam and shock resistance. It is widely used for water-based liquid level detection in industrial automation equipment. RoHS compliant, suitable for packaging and food machinery.
| 属性名称 | 属性值 |
|---|---|
| Brand | SICK |
| Model | CQF16-06EPSEW1 |
| Order No. | 6068622 |
| Product Type | Capacitive proximity sensor |
| Shape | Square |
| Dimension | 16 mm × 34 mm × 8 mm |
| Sensing range | 0.5 mm ... 6 mm |
| Flush mounting | Yes |
| Output | PNP, Normally open |
| Electrical type | DC 4-wire |
| Supply voltage | 10 V DC ... 30 V DC |
| Max. switching current | 100 mA |
| Switching frequency | 10 Hz |
| Connection | 2 m PVC cable, 4-core |
| Cable cross-section | 0.14 mm² |
| Enclosure material | PBT plastic |
| Protection class | IP67, IP68, IP69K |
| Operating temperature | -25 ℃ ~ +80 ℃ |
| Storage temperature | -40 ℃ ~ +85 ℃ |
| Feature | Teach-in function, detect water-based liquid up to 50 mS/cm |
| Accessory | 1 pcs mounting bracket BEF-WMCQF16 |
| Certificate | CE, UKCA, cULus, China RoHS |
| Condition | New Original |
| Net Weight | 0.04 kg |
| Gross Weight | 0.06 kg |
