DZH-25-125-PPV-A
Product Overview
FESTO DZH-25-125-PPV-A belongs to DZH flat cylinder series, double acting single rod design. Equivalent bore 25mm, stroke 125mm, PPV adjustable pneumatic cushion on both sides to reduce impact. Adopts oval piston for anti-torsion, restricts rod rotation within ±2.4°. Built-in T-slot to mount magnetic proximity sensors. Ultra-flat aluminium profile saves installation height. Hard chrome piston rod, stable PU/NBR sealing system. LABS(PWIS) compliant, suitable for paint workshop and lithium battery automation. Any installation orientation, ideal for machines with narrow mounting space.
| 属性名称 | 属性值 |
|---|---|
| Brand | FESTO |
| Model | DZH-25-125-PPV-A |
| Order No. | 151126 |
| Product Series | DZH |
| Product Type | Flat Double-Acting Pneumatic Cylinder |
| Operation | Double acting, single-ended piston rod |
| Equivalent Bore | 25 mm |
| Stroke | 125 mm |
| Piston Rod Thread | M10×1.25 external thread |
| Cushioning | PPV: Pneumatic adjustable cushioning at both ends |
| Theoretical Force @6bar | Advance 295 N, Retract 247 N |
| Operating Pressure | 1 ~ 10 bar |
| Anti-rotation | Oval piston, max torsion angle ±2.4°, max torque 0.8 Nm |
| Cushion Length | 17 mm |
| Ambient Temperature | -20 ~ +80 ℃ |
| Medium | Compressed air ISO 8573-1:2010 [7:4:4], lubricated air optional |
| Barrel | Hard-anodized aluminium profile |
| Piston Rod | Hard chrome plated high-alloy steel |
| Seal | NBR / PU |
| Feature | A: with sensor slot for proximity switch; oval piston anti-torsion, ultra-flat compact structure, LABS(PWIS) compliant VDMA24364-B2-L |
| Mounting | Any mounting position |
| Corrosion Resistance Class | CRC2 |
| Weight | 557 g |
| Certificate | CE, RoHS |
| Origin | Germany |
| Condition | New Original |
